VLP5610T-100MR65
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 10UH 650MA 450 MOHM
- CategoryFixed Inductors
- Datasheet VLP5610T-100MR65 Datasheet
-
ECAD Model
- Share
In Stock: 1,974
Can ship immediately
Pricing:
- 1$1.36
- 3,000$0.6014
Quote It
Technical Details
- Series:VLP
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Type:Wirewound
- Material - Core:-
- Inductance:10 µH
- Tolerance:±20%
- Current Rating (Amps):650 mA
- Current - Saturation (Isat):720mA
- Shielding:Unshielded
- DC Resistance (DCR):450mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.220" L x 0.197" W (5.60mm x 5.00mm)
- Height - Seated (Max):0.039" (1.00mm)
