NS12565T330MN
TAIYO YUDEN
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 33UH 3.22A 46.8 MOHM
- CategoryFixed Inductors
- Datasheet NS12565T330MN Datasheet
-
ECAD Model
- Share
In Stock: 1,373
Can ship immediately
Pricing:
- 1$1.39
- 500$0.7128
- 1,000$0.6336
- 2,500$0.6138
- 5,000$0.594
- 12,500$0.5742
Quote It
Technical Details
- Series:NS
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:33 µH
- Tolerance:±20%
- Current Rating (Amps):3.22 A
- Current - Saturation (Isat):3.89A
- Shielding:Shielded
- DC Resistance (DCR):46.8mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:9.1MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.492" L x 0.492" W (12.50mm x 12.50mm)
- Height - Seated (Max):0.270" (6.85mm)
