CDRH60D45BT150NP-4R7NC
Sumida Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 4.7UH 3.4A 29.9 MOHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 2,175
Can ship immediately
Pricing:
- 1$1.47
Quote It
Technical Details
- Series:CDRH60D45B/T150
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:-
- Material - Core:Ferrite
- Inductance:4.7 µH
- Tolerance:±30%
- Current Rating (Amps):3.4 A
- Current - Saturation (Isat):4.1A
- Shielding:Shielded
- DC Resistance (DCR):29.9mOhm
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-55°C ~ 150°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.260" L x 0.248" W (6.60mm x 6.30mm)
- Height - Seated (Max):0.189" (4.80mm)
