UP2B-220-R
PowerStor (Eaton)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22UH 2.8A 61.7 MOHM
- CategoryFixed Inductors
- Datasheet UP2B-220-R Datasheet
-
ECAD Model
- Share
In Stock: 4,525
Can ship immediately
Pricing:
- 1$1.79
- 550$0.9129
- 1,100$0.83235
- 2,750$0.8055
- 5,500$0.77865
- 13,750$0.7518
Quote It
Technical Details
- Series:UNI-PAC™
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:22 µH
- Tolerance:±20%
- Current Rating (Amps):2.8 A
- Current - Saturation (Isat):2A
- Shielding:Unshielded
- DC Resistance (DCR):61.7mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.550" L x 0.410" W (13.97mm x 10.41mm)
- Height - Seated (Max):0.236" (6.00mm)
