B82477P2105M000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1MH 530MA 1.3 OHM SMD
- CategoryFixed Inductors
- Datasheet B82477P2105M000 Datasheet
-
ECAD Model
- Share
In Stock: 1,246
Can ship immediately
Pricing:
- 1$2.14
- 600$1.23373
Quote It
Technical Details
- Series:B82477P2
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:1 mH
- Tolerance:±20%
- Current Rating (Amps):530 mA
- Current - Saturation (Isat):400mA
- Shielding:Shielded
- DC Resistance (DCR):1.3Ohm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-55°C ~ 150°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.492" L x 0.492" W (12.50mm x 12.50mm)
- Height - Seated (Max):0.256" (6.50mm)
