ASPIAIG-F5030-R80M-T
Abracon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 800NH 13.1A 5.65 MOHM
- CategoryFixed Inductors
- Datasheet ASPIAIG-F5030-R80M-T Datasheet
-
ECAD Model
- Share
In Stock: 2,024
Can ship immediately
Pricing:
- 1$2.02
Quote It
Technical Details
- Series:ASPIAIG-F
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Molded
- Material - Core:-
- Inductance:800 nH
- Tolerance:±20%
- Current Rating (Amps):13.1 A
- Current - Saturation (Isat):18A
- Shielding:Shielded
- DC Resistance (DCR):5.65mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:5030
- Size / Dimension:0.217" L x 0.209" W (5.50mm x 5.30mm)
- Height - Seated (Max):0.122" (3.10mm)
