SPM6550T-1R5M-HZ
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1.5UH 17.1A 6.49 MOHM
- CategoryFixed Inductors
- Datasheet SPM6550T-1R5M-HZ Datasheet
-
ECAD Model
- Share
In Stock: 1,494
Can ship immediately
Pricing:
- 1$2.28
Quote It
Technical Details
- Series:SPM-HZ
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Metal
- Inductance:1.5 µH
- Tolerance:±20%
- Current Rating (Amps):17.1 A
- Current - Saturation (Isat):7.7A
- Shielding:Shielded
- DC Resistance (DCR):6.49mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.280" L x 0.256" W (7.10mm x 6.50mm)
- Height - Seated (Max):0.197" (5.00mm)
