PM2203.161NLT
PulseLarsen Antenna
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 160NH 22.2A 2.33 MOHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 183
Can ship immediately
Pricing:
- 1$2.4
Quote It
Technical Details
- Series:PM2203.XXXNLT
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:-
- Material - Core:-
- Inductance:160 nH
- Tolerance:±20%
- Current Rating (Amps):22.2 A
- Current - Saturation (Isat):35A
- Shielding:Unshielded
- DC Resistance (DCR):2.33mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-55°C ~ 155°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:SMD
- Size / Dimension:0.217" L x 0.209" W (5.50mm x 5.30mm)
- Height - Seated (Max):0.122" (3.10mm)
