PA4320.153NLT
PulseLarsen Antenna
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 15UH 7A 22 MOHM SMD
- CategoryFixed Inductors
- Datasheet PA4320.153NLT Datasheet
-
ECAD Model
- Share
In Stock: 114
Can ship immediately
Pricing:
- 1$2.57
- 300$1.35
- 600$1.275
- 900$1.2
- 1,500$1.1625
- 3,000$1.125
- 7,500$1.0875
Quote It
Technical Details
- Series:PA4320
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:-
- Inductance:15 µH
- Tolerance:±20%
- Current Rating (Amps):7 A
- Current - Saturation (Isat):8.3A
- Shielding:Shielded
- DC Resistance (DCR):22mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.472" L x 0.472" W (12.00mm x 12.00mm)
- Height - Seated (Max):0.402" (10.20mm)
