744355090
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 900NH 24A 1.6 MOHM SMD
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 561
Can ship immediately
Pricing:
- 1$3.27
- 400$2.341
Quote It
Technical Details
- Series:WE-HCI
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:-
- Inductance:900 nH
- Tolerance:±20%
- Current Rating (Amps):24 A
- Current - Saturation (Isat):28A
- Shielding:Shielded
- DC Resistance (DCR):1.6mOhm
- Q @ Freq:-
- Frequency - Self Resonant:72MHz
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 155°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:1350
- Size / Dimension:0.512" L x 0.504" W (13.00mm x 12.80mm)
- Height - Seated (Max):0.197" (5.00mm)
