FP3-R20-R
PowerStor (Eaton)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 200NH 15.3A 1.88 MOHM
- CategoryFixed Inductors
- Datasheet FP3-R20-R Datasheet
-
ECAD Model
- Share
In Stock: 366
Can ship immediately
Pricing:
- 1$3.51
- 1,700$1.752
- 3,400$1.6936
- 5,100$1.6352
Quote It
Technical Details
- Series:FLAT-PAC 3
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Iron Powder
- Inductance:200 nH
- Tolerance:±15%
- Current Rating (Amps):15.3 A
- Current - Saturation (Isat):20.8A
- Shielding:Unshielded
- DC Resistance (DCR):1.88mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 155°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.285" L x 0.264" W (7.25mm x 6.70mm)
- Height - Seated (Max):0.118" (3.00mm)
