177CDMCCDS-1R0MC

Technical Details

• Series:177CDMCC/DS
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Type:Molded
• Material - Core:Metal
• Inductance:1 µH
• Tolerance:±20%
• Current Rating (Amps):44.6 A
• Current - Saturation (Isat):60.8A
• Shielding:Shielded
• DC Resistance (DCR):1.38mOhm Max

• Q @ Freq:-
• Frequency - Self Resonant:-
• Ratings:-
• Operating Temperature:-55°C ~ 125°C
• Inductance Frequency - Test:100 kHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:SMD
• Size / Dimension:0.675" L x 0.675" W (17.15mm x 17.15mm)
• Height - Seated (Max):0.276" (7.00mm)
