LGJ12565TS-4R2N5R5-H
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 4.2UH 5.5A 11.2 MOHM
- CategoryFixed Inductors
- Datasheet LGJ12565TS-4R2N5R5-H Datasheet
-
ECAD Model
- Share
In Stock: 620
Can ship immediately
Pricing:
- 1$6.6
- 500$4.092
- 1,000$3.828
- 2,500$3.696
Quote It
Technical Details
- Series:LGJ
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:4.2 µH
- Tolerance:±30%
- Current Rating (Amps):5.5 A
- Current - Saturation (Isat):7.3A
- Shielding:Shielded
- DC Resistance (DCR):11.2mOhm
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.492" L x 0.492" W (12.50mm x 12.50mm)
- Height - Seated (Max):0.256" (6.50mm)
