7443630140
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1.4UH 31.5A 1.08 MOHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 333
Can ship immediately
Pricing:
- 1$6.93
- 100$5.04
- 500$4.536
Quote It
Technical Details
- Series:WE-HCF
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Manganese Zinc Ferrite (MnZn)
- Inductance:1.4 µH
- Tolerance:±15%
- Current Rating (Amps):31.5 A
- Current - Saturation (Isat):60A
- Shielding:Shielded
- DC Resistance (DCR):1.08mOhm
- Q @ Freq:-
- Frequency - Self Resonant:52MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.846" L x 0.827" W (21.50mm x 21.00mm)
- Height - Seated (Max):0.551" (14.00mm)
