78438357015
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1.5UH 6.2A 20MOHM SMD
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 1,042
Can ship immediately
Pricing:
- 1$1.81
Quote It
Technical Details
- Series:WE-MAIA
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Iron Alloy
- Inductance:1.5 µH
- Tolerance:±20%
- Current Rating (Amps):6.2 A
- Current - Saturation (Isat):8.5A
- Shielding:Shielded
- DC Resistance (DCR):20mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:48MHz
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:4030
- Size / Dimension:0.161" L x 0.161" W (4.10mm x 4.10mm)
- Height - Seated (Max):0.122" (3.10mm)
