9250A-105-RC
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1MH 70MA 17.5 OHM TH
- CategoryFixed Inductors
- Datasheet 9250A-105-RC Datasheet
-
ECAD Model
- Share
In Stock: 359
Can ship immediately
Pricing:
- 1$1.88
- 10$1.74415
- 100$1.26097
- 500$0.9658
- 1,000$0.85849
- 2,500$0.83955
Quote It
Technical Details
- Series:9250A
- Package:Bulk
- Part Status:Active
- Type:Molded
- Material - Core:Ferrite
- Inductance:1 mH
- Tolerance:±10%
- Current Rating (Amps):70 mA
- Current - Saturation (Isat):40mA
- Shielding:Shielded
- DC Resistance (DCR):17.5Ohm Max
- Q @ Freq:60 @ 790kHz
- Frequency - Self Resonant:3.8MHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:790 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Axial
- Supplier Device Package:-
- Size / Dimension:0.162" Dia x 0.410" L (4.11mm x 10.41mm)
- Height - Seated (Max):-
