7443782012100
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 10UH 20.6A 5 MOHM TH
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 245
Can ship immediately
Pricing:
- 1$5.52
Quote It
Technical Details
- Series:WE-HCFT
- Package:Bulk
- Part Status:Active
- Type:Wirewound
- Material - Core:Manganese Zinc Ferrite (MnZn)
- Inductance:10 µH
- Tolerance:±20%
- Current Rating (Amps):20.6 A
- Current - Saturation (Isat):20.6A
- Shielding:Shielded
- DC Resistance (DCR):5mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:17MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.866" L x 0.669" W (22.00mm x 17.00mm)
- Height - Seated (Max):0.531" (13.50mm)
