SRR5018-221Y
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 220UH 230MA 2.5OHM SMD
- CategoryFixed Inductors
- Datasheet SRR5018-221Y Datasheet
-
ECAD Model
- Share
In Stock: 1,050
Can ship immediately
Pricing:
- 1$0.84
- 500$0.33916
- 1,000$0.27455
- 2,500$0.2584
- 5,000$0.2527
Quote It
Technical Details
- Series:SRR5018
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:220 µH
- Tolerance:±30%
- Current Rating (Amps):230 mA
- Current - Saturation (Isat):300mA
- Shielding:Shielded
- DC Resistance (DCR):2.5Ohm Max
- Q @ Freq:8.7 @ 796kHz
- Frequency - Self Resonant:8MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.228" L x 0.228" W (5.80mm x 5.80mm)
- Height - Seated (Max):0.079" (2.00mm)
