SRU1048-560Y
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 56UH 1.6A 110 MOHM SMD
- CategoryFixed Inductors
- Datasheet SRU1048-560Y Datasheet
-
ECAD Model
- Share
In Stock: 2,142
Can ship immediately
Pricing:
- 1$1.01
- 600$0.3825
- 1,200$0.34
- 3,000$0.3325
Quote It
Technical Details
- Series:SRU1048
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:56 µH
- Tolerance:±30%
- Current Rating (Amps):1.6 A
- Current - Saturation (Isat):1.4A
- Shielding:Shielded
- DC Resistance (DCR):110mOhm
- Q @ Freq:26 @ 2.52MHz
- Frequency - Self Resonant:7MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.394" L x 0.394" W (10.00mm x 10.00mm)
- Height - Seated (Max):0.201" (5.10mm)
