22R154C
Murata Power Solutions
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 150UH 520MA 540 MOHM
- CategoryFixed Inductors
- Datasheet 22R154C Datasheet
-
ECAD Model
- Share
In Stock: 879
Can ship immediately
Pricing:
- 1$0.59
- 25$0.58
- 50$0.56
- 100$0.54
- 250$0.5
- 500$0.4655
Quote It
Technical Details
- Series:2200R
- Package:Bulk
- Part Status:Active
- Type:Wirewound
- Material - Core:-
- Inductance:150 µH
- Tolerance:±10%
- Current Rating (Amps):520 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):540mOhm Max
- Q @ Freq:90 @ 100kHz
- Frequency - Self Resonant:5.7MHz
- Ratings:-
- Operating Temperature:-25°C ~ 70°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Vertical Cylinder
- Supplier Device Package:-
- Size / Dimension:0.256" Dia (6.50mm)
- Height - Seated (Max):0.413" (10.50mm)
