SDR1307-6R8ML
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 6.8UH 6A 17 MOHM SMD
- CategoryFixed Inductors
- Datasheet SDR1307-6R8ML Datasheet
-
ECAD Model
- Share
In Stock: 854
Can ship immediately
Pricing:
- 1$1
- 400$0.4641
- 800$0.3757
- 1,200$0.3536
- 2,800$0.3458
Quote It
Technical Details
- Series:SDR1307
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:6.8 µH
- Tolerance:±20%
- Current Rating (Amps):6 A
- Current - Saturation (Isat):10.5A
- Shielding:Unshielded
- DC Resistance (DCR):17mOhm Max
- Q @ Freq:24 @ 7.96MHz
- Frequency - Self Resonant:26MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.512" L x 0.512" W (13.00mm x 13.00mm)
- Height - Seated (Max):0.287" (7.30mm)
