VLCF5028T-3R3N1R7-2
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 3.3UH 1.74A 37 MOHM
- CategoryFixed Inductors
- Datasheet VLCF5028T-3R3N1R7-2 Datasheet
-
ECAD Model
- Share
In Stock: 870
Can ship immediately
Pricing:
- 1$1.22
- 500$0.63
- 1,000$0.56
- 2,500$0.5425
- 5,000$0.525
- 12,500$0.5075
Quote It
Technical Details
- Series:VLCF
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:3.3 µH
- Tolerance:±30%
- Current Rating (Amps):1.74 A
- Current - Saturation (Isat):1.74A
- Shielding:Shielded
- DC Resistance (DCR):37mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 105°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.197" L x 0.197" W (5.00mm x 5.00mm)
- Height - Seated (Max):0.110" (2.80mm)
