RLB0913-223K
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22MH 80MA 56 OHM TH
- CategoryFixed Inductors
- Datasheet RLB0913-223K Datasheet
-
ECAD Model
- Share
In Stock: 304
Can ship immediately
Pricing:
- 1$0.75
- 10$0.65431
- 100$0.4672
- 500$0.39241
- 1,000$0.31765
- 2,500$0.29897
Quote It
Technical Details
- Series:RLB0913
- Package:Tray
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:22 mH
- Tolerance:±10%
- Current Rating (Amps):80 mA
- Current - Saturation (Isat):30mA
- Shielding:Unshielded
- DC Resistance (DCR):56Ohm
- Q @ Freq:30 @ 79.6kHz
- Frequency - Self Resonant:100kHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:1 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Vertical Cylinder
- Supplier Device Package:-
- Size / Dimension:0.335" Dia (8.50mm)
- Height - Seated (Max):0.492" (12.50mm)
