PM3340-150M-RC
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 15UH 3A 42 MOHM SMD
- CategoryFixed Inductors
- Datasheet PM3340-150M-RC Datasheet
-
ECAD Model
- Share
In Stock: 425
Can ship immediately
Pricing:
- 1$1.22
- 225$0.69911
- 450$0.62476
- 675$0.5355
- 1,125$0.476
- 5,625$0.4655
Quote It
Technical Details
- Series:PM3340
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:15 µH
- Tolerance:±20%
- Current Rating (Amps):3 A
- Current - Saturation (Isat):7A
- Shielding:Unshielded
- DC Resistance (DCR):42mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-55°C ~ 105°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.512" L x 0.402" W (13.00mm x 10.20mm)
- Height - Seated (Max):0.453" (11.50mm)
