PD0120.113NL
PulseLarsen Antenna
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 12.2UH 7.6A 16 MOHM
- CategoryFixed Inductors
- Datasheet PD0120.113NL Datasheet
-
ECAD Model
- Share
In Stock: 681
Can ship immediately
Pricing:
- 1$3.05
- 10$2.81793
- 100$1.97255
- 500$1.59683
- 1,000$1.45593
- 2,500$1.40897
Quote It
Technical Details
- Series:PD0120NL
- Package:Tray
- Part Status:Active
- Type:Wirewound
- Material - Core:-
- Inductance:12.2 µH
- Tolerance:±10%
- Current Rating (Amps):7.6 A
- Current - Saturation (Isat):9A
- Shielding:Unshielded
- DC Resistance (DCR):16mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:-
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.638" L x 0.628" W (16.20mm x 15.95mm)
- Height - Seated (Max):0.323" (8.20mm)
