7447720068
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 6.8UH 3.9A 32 MOHM TH
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 322
Can ship immediately
Pricing:
- 1$0.79
Quote It
Technical Details
- Series:WE-TI
- Package:Tray
- Part Status:Active
- Type:Wirewound
- Material - Core:-
- Inductance:6.8 µH
- Tolerance:±20%
- Current Rating (Amps):3.9 A
- Current - Saturation (Isat):6A
- Shielding:Unshielded
- DC Resistance (DCR):32mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:36MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial, Vertical Cylinder
- Supplier Device Package:-
- Size / Dimension:0.307" Dia (7.80mm)
- Height - Seated (Max):0.394" (10.00mm)
