LTF4022T-470M-D
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 47UH 590MA 760 MOHM
- CategoryFixed Inductors
- Datasheet LTF4022T-470M-D Datasheet
-
ECAD Model
- Share
In Stock: 624
Can ship immediately
Pricing:
- 1$1.73
- 500$0.8869
- 1,000$0.78835
- 2,500$0.76372
- 5,000$0.73908
- 12,500$0.71445
Quote It
Technical Details
- Series:LTF4022-D
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:47 µH
- Tolerance:±20%
- Current Rating (Amps):590 mA
- Current - Saturation (Isat):460mA
- Shielding:Shielded
- DC Resistance (DCR):760mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 150°C
- Inductance Frequency - Test:1 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:2-SMD
- Supplier Device Package:-
- Size / Dimension:0.217" L x 0.157" W (5.50mm x 4.00mm)
- Height - Seated (Max):0.087" (2.20mm)
