SPM10054T-1R5M-HZ
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1.5UH 20A 5.39MOHM SMD
- CategoryFixed Inductors
- Datasheet SPM10054T-1R5M-HZ Datasheet
-
ECAD Model
- Share
In Stock: 1,125
Can ship immediately
Pricing:
- 1$2.75
Quote It
Technical Details
- Series:SPM-HZ
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Metal
- Inductance:1.5 µH
- Tolerance:±20%
- Current Rating (Amps):20 A
- Current - Saturation (Isat):12A
- Shielding:Shielded
- DC Resistance (DCR):5.39mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.421" L x 0.394" W (10.70mm x 10.00mm)
- Height - Seated (Max):0.213" (5.40mm)
