• Lifecycle status Active
  • RoHS RoHS Compliant
  • DescriptionFIXED IND 18UH 4.2A 39 MOHM SMD
  • CategoryFixed Inductors
  • ECAD Model
  • Share
In Stock: 695

Can ship immediately

Pricing:
  • 1$1.39
  • 500$1.39

Quote It

Technical Details

  • Series:WE-PD
  • Package:Tape & Reel (TR)
  • Part Status:Active
  • Type:Wirewound
  • Material - Core:Ferrite
  • Inductance:18 µH
  • Tolerance:±20%
  • Current Rating (Amps):4.2 A
  • Current - Saturation (Isat):5.4A
  • Shielding:Shielded
  • DC Resistance (DCR):39mOhm Max



  • Q @ Freq:-
  • Frequency - Self Resonant:13.2MHz
  • Ratings:AEC-Q200
  • Operating Temperature:-40°C ~ 125°C
  • Inductance Frequency - Test:1 kHz
  • Features:-
  • Mounting Type:Surface Mount
  • Package / Case:Nonstandard
  • Supplier Device Package:-
  • Size / Dimension:0.472" L x 0.472" W (12.00mm x 12.00mm)
  • Height - Seated (Max):0.315" (8.00mm)

Related Products


74477010W

FIXED IND 10UH 5.8A 27 MOHM SMD

  • 1: $2.25000
  • 500: $ 1.39000

74456233

FIXED IND 330UH 700MA 1.15 OHM

  • 1: $2.02000

SBCP-11HY471H

FIXED IND 470UH 660MA 760 MOHM

  • 1: $2.53000

1210R-152J

FIXED IND 1.5UH 467MA 850 MOHM

1210R-152J Datasheet
  • 1: $2.69000
  • 500: $ 0.93840
  • 1000: $0.85560

1210R-272J

FIXED IND 2.7UH 411MA 1.1 OHM

1210R-272J Datasheet
  • 1: $2.69000
  • 500: $ 0.93840
  • 1000: $0.85560

DFEH12060D-3R3M=P3

FIXED IND 3.3UH 13A 6.3 MOHM

DFEH12060D-3R3M=P3 Datasheet
  • 1: $2.97000
  • 500: $1.55210
  • 1000: $1.41515

18R153C

FIXED IND 15UH 3A 18 MOHM TH

18R153C Datasheet
  • 1: $1.42000
  • 100: $ 1.29000

18R335C

FIXED IND 3.3MH 220MA 3.5 OHM TH

18R335C Datasheet
  • 1: $1.42000
  • 100: $ 1.29000

18R154C

FIXED IND 150UH 1.1A 165 MOHM TH

18R154C Datasheet
  • 1: $1.42000
  • 10: $1.40000
  • 25: $1.39000

VLBU1007090T-R10L
