PQ2617BHA-3R3K
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 3.3UH 28A 2.5 MOHM SMD
- CategoryFixed Inductors
- Datasheet PQ2617BHA-3R3K Datasheet
-
ECAD Model
- Share
In Stock: 200
Can ship immediately
Pricing:
- 1$4.17
Quote It
Technical Details
- Series:PQ2617BHA
- Package:Tray
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:3.3 µH
- Tolerance:±10%
- Current Rating (Amps):28 A
- Current - Saturation (Isat):92.5A
- Shielding:Shielded
- DC Resistance (DCR):2.5mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:40MHz
- Ratings:AEC-Q200
- Operating Temperature:-40°C ~ 155°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:1.098" L x 0.780" W (27.90mm x 19.80mm)
- Height - Seated (Max):0.748" (19.00mm)
