SRP1040VA-220M
J.W. Miller / Bourns
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22UH 6A 72MOHM SMD
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 893
Can ship immediately
Pricing:
- 1$2.14
Quote It
Technical Details
- Series:SRP1040VA
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Metal
- Inductance:22 µH
- Tolerance:±20%
- Current Rating (Amps):6 A
- Current - Saturation (Isat):6.5A
- Shielding:Shielded
- DC Resistance (DCR):72mOhm Max
- Q @ Freq:20 @ 100kHz
- Frequency - Self Resonant:7MHz
- Ratings:AEC-Q200
- Operating Temperature:-55°C ~ 180°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.433" L x 0.394" W (11.00mm x 10.00mm)
- Height - Seated (Max):0.157" (4.00mm)
