HCM1305-4R7-R
PowerStor (Eaton)- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 4.7UH 12A 12.7 MOHM
- CategoryFixed Inductors
- Datasheet HCM1305-4R7-R Datasheet
-
ECAD Model
- Share
In Stock: 576
Can ship immediately
Pricing:
- 1$1.98
- 400$1.98
Quote It
Technical Details
- Series:HCM1305
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Iron Powder
- Inductance:4.7 µH
- Tolerance:±20%
- Current Rating (Amps):12 A
- Current - Saturation (Isat):27A
- Shielding:Shielded
- DC Resistance (DCR):12.7mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.524" L x 0.480" W (13.30mm x 12.20mm)
- Height - Seated (Max):0.197" (5.00mm)
