L-05B1N0SV6T
Johanson Technology
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1NH 300MA 120 MOHM SMD
- CategoryFixed Inductors
- Datasheet L-05B1N0SV6T Datasheet
-
ECAD Model
- Share
In Stock: 5,034
Can ship immediately
Pricing:
- 1$0.1
- 15,000$0.01105
- 30,000$0.0104
- 75,000$0.01008
- 105,000$0.00975
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Multilayer
- Material - Core:Ceramic
- Inductance:1 nH
- Tolerance:±0.3nH
- Current Rating (Amps):300 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):120mOhm Max
- Q @ Freq:4 @ 100MHz
- Frequency - Self Resonant:13GHz
- Ratings:-
- Operating Temperature:-55°C ~ 100°C
- Inductance Frequency - Test:100 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0201 (0603 Metric)
- Supplier Device Package:0201 (0603 Metric)
- Size / Dimension:0.024" L x 0.012" W (0.60mm x 0.30mm)
- Height - Seated (Max):0.013" (0.33mm)
