MHQ0402PSA1N7BT000
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1.7NH 400MA 400 MOHM
- CategoryFixed Inductors
- Datasheet MHQ0402PSA1N7BT000 Datasheet
-
ECAD Model
- Share
In Stock: 470
Can ship immediately
Pricing:
- 1$0.1
- 20,000$0.0304
- 40,000$0.02945
- 60,000$0.0285
- 100,000$0.02755
Quote It
Technical Details
- Series:MHQ-PSA
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Multilayer
- Material - Core:Ceramic
- Inductance:1.7 nH
- Tolerance:±0.1nH
- Current Rating (Amps):400 mA
- Current - Saturation (Isat):-
- Shielding:Shielded
- DC Resistance (DCR):400mOhm Max
- Q @ Freq:10 @ 500MHz
- Frequency - Self Resonant:10GHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:500 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:01005 (0402 Metric)
- Supplier Device Package:-
- Size / Dimension:0.016" L x 0.008" W (0.40mm x 0.20mm)
- Height - Seated (Max):0.009" (0.22mm)
