MLZ2012A2R2WT000
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.2UH 650MA 150 MOHM
- CategoryFixed Inductors
- Datasheet MLZ2012A2R2WT000 Datasheet
-
ECAD Model
- Share
In Stock: 211
Can ship immediately
Pricing:
- 1$0.13
- 4,000$0.04875
- 8,000$0.04604
- 12,000$0.04333
- 28,000$0.04198
- 100,000$0.03927
Quote It
Technical Details
- Series:MLZ
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Multilayer
- Material - Core:Ferrite
- Inductance:2.2 µH
- Tolerance:±20%
- Current Rating (Amps):650 mA
- Current - Saturation (Isat):210mA
- Shielding:Shielded
- DC Resistance (DCR):150mOhm
- Q @ Freq:-
- Frequency - Self Resonant:120MHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:10 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0805 (2012 Metric)
- Supplier Device Package:0805 (2012 Metric)
- Size / Dimension:0.079" L x 0.049" W (2.00mm x 1.25mm)
- Height - Seated (Max):0.041" (1.05mm)
