CIG22B2R2MNE
Samsung Electro-Mechanics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.2UH 1.1A 183 MOHM
- CategoryFixed Inductors
- Datasheet CIG22B2R2MNE Datasheet
-
ECAD Model
- Share
In Stock: 561
Can ship immediately
Pricing:
- 1$0.18
- 3,000$0.09631
- 6,000$0.09064
- 15,000$0.08781
- 30,000$0.08498
- 75,000$0.08214
Quote It
Technical Details
- Series:CIG22B
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Type:Multilayer
- Material - Core:-
- Inductance:2.2 µH
- Tolerance:±20%
- Current Rating (Amps):1.1 A
- Current - Saturation (Isat):1.2A
- Shielding:Shielded
- DC Resistance (DCR):183mOhm
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:1 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1008 (2520 Metric)
- Supplier Device Package:1008 (2520 Metric)
- Size / Dimension:0.098" L x 0.079" W (2.50mm x 2.00mm)
- Height - Seated (Max):0.039" (1.00mm)
