CBC2016T680K
TAIYO YUDEN
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 68UH 130MA 9.1 OHM SMD
- CategoryFixed Inductors
- Datasheet CBC2016T680K Datasheet
-
ECAD Model
- Share
In Stock: 1,164
Can ship immediately
Pricing:
- 1$0.24
- 2,000$0.1008
- 4,000$0.0864
- 6,000$0.0816
- 10,000$0.0768
- 50,000$0.072
- 100,000$0.0696
Quote It
Technical Details
- Series:CB, C Type
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:68 µH
- Tolerance:±10%
- Current Rating (Amps):130 mA
- Current - Saturation (Isat):130mA
- Shielding:Unshielded
- DC Resistance (DCR):9.1Ohm Max
- Q @ Freq:-
- Frequency - Self Resonant:10MHz
- Ratings:-
- Operating Temperature:-40°C ~ 105°C
- Inductance Frequency - Test:2.52 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0806 (2016 Metric)
- Supplier Device Package:0806 (2016 Metric)
- Size / Dimension:0.079" L x 0.063" W (2.00mm x 1.60mm)
- Height - Seated (Max):0.071" (1.80mm)
