NLCV25T-1R0M-PFR
TDK Corporation
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 1UH 1A 168 MOHM SMD
- CategoryFixed Inductors
- Datasheet NLCV25T-1R0M-PFR Datasheet
-
ECAD Model
- Share
In Stock: 513
Can ship immediately
Pricing:
- 1$0.25
- 2,000$0.099
- 4,000$0.0935
- 6,000$0.088
- 10,000$0.08525
- 50,000$0.07975
- 100,000$0.077
Quote It
Technical Details
- Series:NLCV-PF
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Not For New Designs
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:1 µH
- Tolerance:±20%
- Current Rating (Amps):1 A
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):168mOhm Max
- Q @ Freq:10 @ 7.96MHz
- Frequency - Self Resonant:100MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:7.96 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1008 (2520 Metric)
- Supplier Device Package:1008 (2520 Metric)
- Size / Dimension:0.098" L x 0.079" W (2.50mm x 2.00mm)
- Height - Seated (Max):0.075" (1.90mm)
