LQH32PN6R8NN0L
TOKO / Murata
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 6.8UH 850MA 288 MOHM
- CategoryFixed Inductors
- Datasheet LQH32PN6R8NN0L Datasheet
-
ECAD Model
- Share
In Stock: 517
Can ship immediately
Pricing:
- 1$0.35
- 2,000$0.1413
- 4,000$0.13345
- 6,000$0.1256
- 10,000$0.12168
- 50,000$0.11383
Quote It
Technical Details
- Series:LQH32
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:6.8 µH
- Tolerance:±30%
- Current Rating (Amps):850 mA
- Current - Saturation (Isat):850mA
- Shielding:Shielded
- DC Resistance (DCR):288mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:40MHz
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:1 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:1210 (3225 Metric)
- Size / Dimension:0.126" L x 0.098" W (3.20mm x 2.50mm)
- Height - Seated (Max):0.067" (1.70mm)
