NRS6028T220MMGJ
TAIYO YUDEN
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 22UH 1.4A 175.5 MOHM
- CategoryFixed Inductors
- Datasheet NRS6028T220MMGJ Datasheet
-
ECAD Model
- Share
In Stock: 238
Can ship immediately
Pricing:
- 1$0.36
- 2,000$0.1422
- 4,000$0.1343
- 6,000$0.1264
- 10,000$0.12245
- 50,000$0.11455
Quote It
Technical Details
- Series:NR, S Type
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:22 µH
- Tolerance:±20%
- Current Rating (Amps):1.4 A
- Current - Saturation (Isat):1.3A
- Shielding:Shielded
- DC Resistance (DCR):175.5mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:12MHz
- Ratings:-
- Operating Temperature:-25°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.236" L x 0.236" W (6.00mm x 6.00mm)
- Height - Seated (Max):0.110" (2.80mm)
