744761218C
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 180NH 250MA 1 OHM SMD
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 684
Can ship immediately
Pricing:
- 1$0.38
- 3,000$0.37291
Quote It
Technical Details
- Series:WE-KI
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ceramic
- Inductance:180 nH
- Tolerance:±5%
- Current Rating (Amps):250 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):1Ohm Max
- Q @ Freq:25 @ 100MHz
- Frequency - Self Resonant:990MHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:100 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:0603 (1608 Metric)
- Supplier Device Package:0603 (1608 Metric)
- Size / Dimension:0.065" L x 0.045" W (1.65mm x 1.15mm)
- Height - Seated (Max):0.043" (1.10mm)
