7447629100
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 10UH 340MA 1.975 OHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 897
Can ship immediately
Pricing:
- 1$0.39
- 2,000$0.39
Quote It
Technical Details
- Series:WE-GFH
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:-
- Material - Core:Iron Powder
- Inductance:10 µH
- Tolerance:±10%
- Current Rating (Amps):340 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):1.975Ohm Max
- Q @ Freq:30 @ 2.52MHz
- Frequency - Self Resonant:44MHz
- Ratings:-
- Operating Temperature:-40°C ~ 105°C
- Inductance Frequency - Test:2.52 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:2520
- Size / Dimension:0.098" L x 0.079" W (2.50mm x 2.00mm)
- Height - Seated (Max):0.079" (2.00mm)
