LQH3NPN221MGRL
TOKO / Murata
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 220UH 150MA 9 OHM SMD
- CategoryFixed Inductors
- Datasheet LQH3NPN221MGRL Datasheet
-
ECAD Model
- Share
In Stock: 278
Can ship immediately
Pricing:
- 1$0.39
- 3,000$0.14603
- 6,000$0.13744
- 15,000$0.13315
- 30,000$0.12885
- 75,000$0.12456
Quote It
Technical Details
- Series:LQH3
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:220 µH
- Tolerance:±20%
- Current Rating (Amps):150 mA
- Current - Saturation (Isat):120mA
- Shielding:Shielded
- DC Resistance (DCR):9Ohm Max
- Q @ Freq:-
- Frequency - Self Resonant:2MHz
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:1 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:1212 (3030 Metric)
- Supplier Device Package:1212 (3030 Metric)
- Size / Dimension:0.118" L x 0.118" W (3.00mm x 3.00mm)
- Height - Seated (Max):0.039" (1.00mm)
