NRS5014T2R2NMGG
TAIYO YUDEN
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.2UH 2A 78 MOHM SMD
- CategoryFixed Inductors
- Datasheet NRS5014T2R2NMGG Datasheet
-
ECAD Model
- Share
In Stock: 590
Can ship immediately
Pricing:
- 1$0.4
- 1,000$0.162
Quote It
Technical Details
- Series:NR, S Type
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:2.2 µH
- Tolerance:±30%
- Current Rating (Amps):2 A
- Current - Saturation (Isat):2.8A
- Shielding:Shielded
- DC Resistance (DCR):78mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:56MHz
- Ratings:-
- Operating Temperature:-25°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.197" L x 0.197" W (5.00mm x 5.00mm)
- Height - Seated (Max):0.055" (1.40mm)
