B78148E1683J000
TDK EPCOS
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 68UH 780MA 900 MOHM TH
- CategoryFixed Inductors
- Datasheet B78148E1683J000 Datasheet
-
ECAD Model
- Share
In Stock: 1,055
Can ship immediately
Pricing:
- 1$0.41
- 2,000$0.17425
- 4,000$0.164
- 6,000$0.15888
- 10,000$0.15375
- 50,000$0.1435
Quote It
Technical Details
- Series:BC+
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:68 µH
- Tolerance:±5%
- Current Rating (Amps):780 mA
- Current - Saturation (Isat):720mA
- Shielding:Unshielded
- DC Resistance (DCR):900mOhm Max
- Q @ Freq:45 @ 796kHz
- Frequency - Self Resonant:6.5MHz
- Ratings:-
- Operating Temperature:-55°C ~ 125°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Through Hole
- Package / Case:Radial
- Supplier Device Package:-
- Size / Dimension:0.157" Dia (4.00mm)
- Height - Seated (Max):0.453" (11.50mm)
