36501JR11JTDG
TE Connectivity AMP Connectors
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 110NH 300MA 610 MOHM
- CategoryFixed Inductors
- Datasheet 36501JR11JTDG Datasheet
-
ECAD Model
- Share
In Stock: 444
Can ship immediately
Pricing:
- 1$0.41
- 2,000$0.17197
- 4,000$0.16186
- 6,000$0.1568
- 10,000$0.15174
- 50,000$0.14162
Quote It
Technical Details
- Series:3650, Sigma Inductors
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:-
- Inductance:110 nH
- Tolerance:±5%
- Current Rating (Amps):300 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):610mOhm Max
- Q @ Freq:32 @ 250MHz
- Frequency - Self Resonant:1.35GHz
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:250 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:0603 (1608 Metric)
- Size / Dimension:0.071" L x 0.044" W (1.80mm x 1.12mm)
- Height - Seated (Max):0.040" (1.02mm)
