VLS4012CX-100M-1

Technical Details

• Series:VLS-CX-1
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Type:Wirewound
• Material - Core:Ferrite
• Inductance:10 µH
• Tolerance:±20%
• Current Rating (Amps):1.3 A
• Current - Saturation (Isat):990mA
• Shielding:Shielded
• DC Resistance (DCR):294mOhm Max

• Q @ Freq:-
• Frequency - Self Resonant:-
• Ratings:-
• Operating Temperature:-40°C ~ 105°C
• Inductance Frequency - Test:1 MHz
• Features:-
• Mounting Type:Surface Mount
• Package / Case:Nonstandard
• Supplier Device Package:-
• Size / Dimension:0.157" L x 0.157" W (4.00mm x 4.00mm)
• Height - Seated (Max):0.047" (1.20mm)
