LQH44PN150MJ0L
TOKO / Murata
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 15UH 610MA 462 MOHM
- CategoryFixed Inductors
- Datasheet LQH44PN150MJ0L Datasheet
-
ECAD Model
- Share
In Stock: 543
Can ship immediately
Pricing:
- 1$0.45
- 1,000$0.18167
- 3,000$0.17158
- 5,000$0.16149
- 10,000$0.15644
- 25,000$0.15139
- 50,000$0.14635
Quote It
Technical Details
- Series:LQH44
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:15 µH
- Tolerance:±20%
- Current Rating (Amps):610 mA
- Current - Saturation (Isat):430mA
- Shielding:Shielded
- DC Resistance (DCR):462mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:25MHz
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:100 kHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:1515 (4040 Metric)
- Size / Dimension:0.157" L x 0.157" W (4.00mm x 4.00mm)
- Height - Seated (Max):0.047" (1.20mm)
