MDMK2020T2R2MM
TAIYO YUDEN
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 2.2UH 1.45A 109 MOHM
- CategoryFixed Inductors
- Datasheet MDMK2020T2R2MM Datasheet
-
ECAD Model
- Share
In Stock: 975
Can ship immediately
Pricing:
- 1$0.43
- 2,500$0.16116
- 5,000$0.15168
- 12,500$0.14694
- 25,000$0.1422
- 62,500$0.13746
Quote It
Technical Details
- Series:MCOIL™, MD
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Metal
- Inductance:2.2 µH
- Tolerance:±20%
- Current Rating (Amps):1.45 A
- Current - Saturation (Isat):1.75A
- Shielding:Shielded
- DC Resistance (DCR):109mOhm Max
- Q @ Freq:-
- Frequency - Self Resonant:-
- Ratings:-
- Operating Temperature:-40°C ~ 125°C
- Inductance Frequency - Test:1 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:-
- Size / Dimension:0.079" L x 0.079" W (2.00mm x 2.00mm)
- Height - Seated (Max):0.047" (1.20mm)
