744760347A
Würth Elektronik Midcom
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFIXED IND 4.7UH 180MA 2.8 OHM
- CategoryFixed Inductors
-
ECAD Model
- Share
In Stock: 986
Can ship immediately
Pricing:
- 1$0.44
- 2,000$0.277
Quote It
Technical Details
- Series:WE-RFI
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Active
- Type:Wirewound
- Material - Core:Ferrite
- Inductance:4.7 µH
- Tolerance:±5%
- Current Rating (Amps):180 mA
- Current - Saturation (Isat):-
- Shielding:Unshielded
- DC Resistance (DCR):2.8Ohm Max
- Q @ Freq:15 @ 7.96MHz
- Frequency - Self Resonant:50MHz
- Ratings:-
- Operating Temperature:-40°C ~ 85°C
- Inductance Frequency - Test:7.96 MHz
- Features:-
- Mounting Type:Surface Mount
- Package / Case:Nonstandard
- Supplier Device Package:0805
- Size / Dimension:0.090" L x 0.067" W (2.29mm x 1.70mm)
- Height - Seated (Max):0.058" (1.48mm)
